ELECFREAKS Octopus Digital PushButton Brick - Blue

Octopus Electronic Bricks, you can use them build electronics projects just as easy as piling bricks. By using Octopus electronic bricks, you may connect Arduino/Freaduino compatible boards easily with various digital, analog and I2C/Uart interfaces. These breadboard-less firm connections are prepared to extensive modules like poteniometers, sensors, relays, servos even buttons, just plug and play.

This is a digital push button sensor, which detects your press action. It is ideal for beginner class to test the Arduino or be your first sensor in your project. It was easy to be used for Chipkit, STM32, AVR, ARM, and other mirc-MCU.

The Freaduino Sensor Shield is the perfect shield to connect this senor to Arduino. Or Freaduino UNO which we had pre-stray Octopus Brick interface.

There are two colors for you to choose from, Red and Blue.

FEATURES

3P buckled wires connector
Easy to 'plug and play
Large button keypad and high-quality first-class hat
Able to achieve very interesting and an interactive work

SPECIFICATION

Big button module pin definition: (1) Output (2) VCC (3) GND

PACKAGE LIST

HARDWARE CONNECTION

Connect the push button brick to the P0 port on OCTOPUS:BIT.

CODE

You can see the whole program from the link here: link
Or you can download it from the page below.

RESULT

When the button isn't pressed, micro:bit will display a rectangle; when it is pressed, micro:bit will display a heart.
